PRO 670 - cable drum roller

Product Description

The innovative quality cable drum unwinder from RUNPOTEC, made of light and solid die-cast and continuous cast aluminium with robust, adjustable support rollers, is also excellently suited for the highest loads up to 215 kg in daily use. The support rollers with spring core axles can be easily and quickly adapted to the different cable drum sizes up to max. Ø 1000 mm by adjusting the distance to 85, 160, 225, 290, 310 and 335 mm. The sealed support roller bearings provide protection against contamination and corrosion and thus guarantee maintenance-free running characteristics. The four compact feet made of high-quality plastic always give the cable drum unwinder stable and non-slip based and protect finished floor coverings. The high-quality and functional design with elaborate technology guarantees a long service life. Cable drum unwinders PRO 530 and PRO 670 can be retrofitted with castors!Application video: a short, very informative application video can be viewed by scanning the QR code or on www.RUNPOTEC.com. Scope of supply: 1 x PRO 670 cable drum roller with rubberised handles, stand feet, 2 x support rollers - pre-assembled

Highlights

• Light and solid aluminium die casting and continuous casting
• For maximum stress in daily use.
• Adjustable support rollers for drums up to max. Ø 1 metre
• Robust, sealed support rollers
• Guaranteed maintenance-free operation.
• Compact feet - stable, non-slip base
• Completely pre-assembled
• No installation required for customer

Technical Data

Product family

Cable Roller Systems

Dimensions

575 mm x 765 mm x 95 mm

Weight

12,04 kg (Gross weight)

Material

Light and solid die-cast and continuous cast aluminium

Load bearing capacity

215 kg

Drum width

max. 670 mm

EAN-Code

9120045475654

Origin

Austria

Model group

CAM1
